dose Badge Noise Dosimeters
dose Badge noise dosimeters are the perfect solution
for measuring a worker's noise dose exposure. The badge is
small and light, with no cable or controls and
mounts comfortably on the worker's shoulder. The dosimeters are
left on the worker, storing details about the noise levels
throughout the day.
The dose Badge has no controls or display and all control is over
the infra-red link to the Reader. The dose
Badge case is
a
lightweight alloy, giving added strength to the already
strong cone shape.
The dose Badge contains the microphone, a rechargeable battery
and the electronics to acquire and analyze the levels continuously.
- IEC 61252 and ANSI S1.25 to Type 2
- Suitable for ISO, OSHA, MSHA, AICHE and ACGIH noise applications
- Intrinsically Safe version
available
- No wires or controls on the badge to catch or knock
- Very rugged cast aluminum case
- Powered by a rechargeable battery
- Time History gives
a graph of noise levels
- Noise measurement span from 70 to 130 dB(A)
- True Peak reading from 120 to 140 dB(C)
The Reader
The Reader has a built in dose Badge calibrator and can show the
results of measurements on its display or transfer them to a computer
using the software supplied.
Complete Noise Dosimeter Kits
Complete measurement kits are supplied, including dose
Badge noise
dosimeters, Reader, charging unit, software and dose Badge mounts.
Everything needed to make the noise dose measurements with no
hidden costs. |
